| Quantity: | |
|---|---|
| SPECIFICATIONS FOR CHANNEL STEEL | ||
| INTRODUCTION | Product | channel steel |
| Standard | ASTM,BS,GB,JIS,etc | |
| Grade | SS400, ST37-2, A36, S235JRG1, Q235, Q345 etc | |
| SPECIFICATIONS | Product Keywords | c channel for building |
| manufacturing technique | Hot rolled(elementary) Can be processed again repeatedly | |
| strength of extension | A36/420MPa S355JR/485MPa | |
| Shipping | Technique | Hot Rolled or cold rolled |
| Delivery Time | 10~20days | |
| Shipping | 1)Shipping by containers | |
| 2)Shipping by bulk ship | ||
| SPECIFICATION | SIZE | KG/M |
| 5# | 50*37*4.5 | 5.438 |
| 6.3# | 63*40*4.8 | 6.634 |
| 8# | 80*43*5.0 | 8.045 |
| 10# | 100*48*5.3 | 10.007 |
| 12# | 120*53*5.5 | 12.059 |
| 14#A | 140*58*6.0 | 14.535 |
| 14#B | 140*60*8.0 | 16.733 |
| 16#A | 160*63*6.5 | 17.24 |
| 16#B | 160*65*8.5 | 19.752 |
| 18#A | 180*68*7.0 | 20.174 |
| 18#B | 180*70*9.0 | 23 |
| 20#A | 200*73*7.0 | 22.337 |
| 20#B | 200*75*9.0 | 25.777 |
| 22#A | 220*77*7.0 | 24.999 |
| 22#B | 220*79*9.0 | 28.453 |
| 25#A | 250*78*7.0 | 27.41 |
| 25#B | 250*80*9.0 | 31.335 |
| 25#C | 250*82*11.0 | 35.26 |
| 28#A | 280*82*7.5 | 31.427 |
| 28#B | 280*84*9.5 | 35.823 |
| 28#C | 280*86*11.5 | 40.219 |
| 30#A | 300*85*7.5 | 34.463 |
| 30#B | 300*87*9.5 | 39.173 |
| 30#C | 300*89*11.5 | 43.883 |
| 32#A | 320*88*8.0 | 38.083 |
| 32#B | 320*90*10.0 | 43.107 |
| 32#C | 320*92*12.0 | 48.131 |
| 36#A | 360*96*9.0 | 47.814 |
| 36#B | 360*98*11.0 | 53.466 |
| 36#C | 360*100*13.0 | 59.118 |
| 40#A | 400*100*10.5 | 58.928 |
| 40#B | 400*102*12.5 | 65.204 |
| 40#C | 400*104*14.5 | 71.488 |
